DMC-6045 DMC-12045 DMC-8045 DMC-10045
X/Y/Z-axis Travel (mm) 6,000*4,500*1,500 12000*4,700*1,500 8000*4,500*1,500 10000*4,500*1,500
Worktable Size (mm) 6,000*3,000 12,000*3,000 8,000*3,000 10,000*3,000
Spindle Motor (kw) 26/840 NM 26/840 22/26 26/840
Axis Motor (kw) 6*4/6/6 9*4/7/7 6*4/6/6 6*4/6/6
Cutting Speed (mm/min) 1-5,000 1-5,000 1-5,000 1-5,000
X/Y/Z Rapid Traverse (m/min) 9/10/10 9/10/10 9/10/10 9/10/10

1.Takam Machines Quality tests includes:

- Half complete 3-axis accuracy check

- Half complete 48 hours test run

- Complete 3-axis accuracy check

- Complete 48 hours test run

- 100% complete check

2.With the moving column design, customer is able to load heavier work piece on to the worktable without any hesitation.

3.The Takam DMC Series customer can customize and choose which ever length it is the best fit for their work environment. So the customer can save the most for the budget they are spending.
