| model subject |
TA-745 | TA-855 |
| Work table size (mm) | 900*450 | 900*550 |
| Machining area (mm) | 700*420 | 800*520 |
| X/Y/Z Axis travel (mm) | 700/420/550 | 800/520/550 |
| Axis motor（Mitsubishi） (kw) | 1.5/1.5/3.0BS | 1.5/1.5/3.0BS |
| Axis motor（Fanuc） (kw) | 1.8/1.8/3.0BS | 1.8/1.8/3.0BS |
| Cutting feed rate（X/Y/Z Axis） (mm/min) | 1-10,000 | 1-10,000 |
| Rapid feed rate（X/Y/Z Axis） (m/min) | 36/36/36 | 36/36/36 |
| (X/Y/Z Axis) Linear guideway | 35/35/35(Roller) | 35/35/35(Roller) |
1.Takam Machines Quality tests includes:
- Half complete 3-axis accuracy check
- Half complete 48 hours test run
- Complete 3-axis accuracy check
- Complete 48 hours test run
- 100% complete check
2.The TA-Series is compatible with multiple type of controllers, giving customer different options to choose for their machine set up.
3.The TA-Series is supplied to many technical schools around the globe for education training.
4.With our extraordinary machine body design, it is the widest and the heaviest in its class.
