                                          model
subject
TE-855 TE-855D TE-1060 TE-1270 TE-1370 TE-1470
Work table size (mm) 1,000*550 1,000*550 1,100*600 1,300*700 1,400*700 1,500*700
Machining area (mm) 850*550 850*550 1,000*600 1,200*700 1,300*700 1400*700
X/Y/Z Axis travel (mm) 850*550*550 850*550*550 1,000*620*600 1,200*720*700 1,300*720*700 1,400*720*700
Axis motorMitsubishi (kw) 1.5/1.5/3.0 1.5/1.5/3.0 3/3/3 3/3/3 3/3/3 3/3/3
Axis motorFanuc  (kw) 1.8/1.8/3.0 1.8/1.8/3.0 3/3/3 3/3/3 3/3/3 3/3/3
Cutting feed rateX/Y/Z Axis (mm/min) 1-10,000 1-10,000 1-12,000 1-10,000 1-10,000 1-10,000
Rapid feed rateX/Y/Z Axis (m/min) 48/48/48 48/48/24 36/36/36 24/24/24 24/24/24 24/24/24
(X/Y/Z Axis) Linear guideway 45/45/45(Roller) 35/35/35(Box way) 45/45/45(Roller) 45/45/45(Roller) 45/45/45(Roller) 45/45/45(Roller)

        - Half complete 3-axis accuracy check1.Takam Machines Quality tests includes:

        - Half complete 48 hours test run

        - Complete 3-axis accuracy check

        - Complete 48 hours test run

        - 100% complete check

2.Extra wide base- the base of the Takam TE-Series is wider than its travel, with a revolutionary design in its column design, giving the machine the perfect triangular balance in the machine structure to give the maximum stability and rigidity. Giving the machine the capability of stable performance in parts production and mold production.

3.In the larger size TE-Series machine we are equipped with 4-Linear roller type linear guide ways, giving the machine a smoother and more reliable base for the performance. For sizes TE-1270/1370/1470 it is capable to of interchanging between BT40 and BT50 to maximize the customer choice on the machine selection.

Model NO.: TE-655
Model NO.: TE-855
Model NO.: TE-855D
Model NO.: TE-1060
Model NO.: TE-1260
Model NO.: TE-1270
Model NO.: TE-1370
Model NO.: TE-1470
